Overall System Performance: |
|
Carrier Frequency Ranges |
VHF,160-270MHz |
|
Frequency Stability |
+/-0.005% |
|
Modulation |
+/-15 KHz normal |
|
Frequency Response |
70Hz-17KHz,-3dB |
|
Dynamic Range |
110dB |
|
Total Harmonic Distortion |
<0.7% |
|
Working Range |
Up
to 100m (approximately 300ft depends on site & conditions) |
|
Receiver: |
|
Reception Mode |
Crystal lock (Dual Antenna) |
|
Sensitivity |
:4uV |
|
Unwanted Signal Rejection |
<80dB image and spurious |
|
Squelch |
External Control, Tone Key |
|
Power Requirement |
DC 12-16V, AC/DC adapter included |
|
Dimension (DxWxH) |
420
x 207 x 44 mm |
|
Weight |
Approx. 2.3kg |
