Description:
The latest
evolution in wireless microphone technology is now available in the all new
IDOLPRO UHF-333 FREE STYLE UHF DUAL WIRELESS MICROPHONE SYSTEM, which features
32 Selectable Channels in the Ultra High Frequency range between 700-900MHz.
This allows for a much wider usage range than set frequency microphones and is
ideal for the Karaoke Professional working with multiple systems. The wide range
of selectable frequencies virtually eliminates unwanted interference and
accompanying sonic distortion. The UHF-333 incorporates new patented PLL
synthesized oscillator technology for stability, dynamic range and frequency
response as well as Ultra High Speed MCU signal analyzer to control noise and
shock for perfect tone. Combined with IDOLPRO’s famous Crystal Clear Sound
technology and traditional professional product durability, the UHF-333 emerges
as THE unqualified Best Choice for a UHF Dual Wireless Microphone System.
Special Features:
- Dual channel Diversity
- Uni-Directional condenser element.
- Superb
Isolation and Unsurpassed
- Smart RF indicator meter display
- Frequency
display
- Full metal housing
- Tone control quelch
- Steel durable grille tip
- Noise Absorption
- Low Battery consumption.
- Super cardioid pattern at 120 off-axis.
- Working Range Adjustable
Specifications:
|
Overall System
Performance: |
|
Carrier Frequency Ranges |
UHF 700-900MHZ
|
| Channel
Total |
16x2 |
|
Frequency Stability |
+/-0.005% |
|
Modulation |
+/-15 KHz normal |
|
Frequency Response |
35hz-20khz
3db |
|
Dynamic Range |
<110dB |
|
Total Harmonic Distortion |
>0.5% |
|
Working Range |
Up
to 100m (approximately 300ft depends on site & conditions) |
|
Receiver: |
| Sensitivity
|
2.0uV |
|
Sensitivity Range |
12~32dBuV |
| Harmonic
Interference Ratio |
>75dB |
| Audio
Output |
Balanced
0~0.5V/100ohm, Unbalanced 0~0.5V/5k ohm |
|
Power Requirement |
DC 12.5~16V |
|
Microphone |
| Power
Requirements |
10mw |
| Frequency
Vibration Mode |
PPL |
| Modulation
Mode |
FM |
| Image And
Spurious Rejection |
More than
50db |
| Bored Upon
Channel Rejection |
Less than
75KDB |
| Channel
Switch Mode |
Coding
Switch |
| Voltage |
DC2.4-7.2v
(2DC 1.2v, 1.5v, 3.6v) |
Package Include:
IDOLpro UHF-333 2 Microphones
IDOLpro UHF-333 Receiver
Batteries
MManual
